Web SDK

Learn how to quickly integrate with the Predictive Document Verification (DocV) Web SDK.

📘

Note:

To utilize RiskOS™, your DocV Web SDK integration must be on version 5 (v5) or later.


Before you start

Make sure you have the following:

Get a valid API key from the Developer Workbench > API Keys page in RiskOS™.
Get a valid SDK key from the Developer Workbench > SDK Keys page in RiskOS™.
(Optional) Add your IP address to the allowlist in RiskOS™.

Step 1: Generate a transaction token and configure the Capture App

To initiate the verification process, generate a transaction token (docvTransactionToken) by calling the Evaluation endpoint. We strongly recommend that customers generate this token via a server-to-server API call and then pass it to the DocV SDK to ensure the security of their API key and any data they send to Socure.


Call the Evaluation endpoint

  1. From your backend, make a POST request to the /api/evaluation endpoint specifying the following information in the config object:
ParameterRequiredDescription
languageOptional

Determines the language package for the UI text on the Capture App.

Note: Socure can quickly add support for any new language requirement that is not listed above. For more information, contact [email protected].

use_case_keyOptional

Deploys a customized Capture App flow on a per-transaction basis. Replace the customer_use_case_key value with the name of the flow you created in RiskOS™.

  • If this field is empty, the Capture App will use the flow marked as Default in RiskOS™.
  • If the value provided is incorrect, the SDK will return an Invalid Request error.
📘

Note:

We recommend including as much consumer PII in the body of the request as possible to return the most accurate results.

curl --location 'https://riskos.socure.com/api/evaluation' \
  --header 'accept: application/json' \
  --header 'authorization: Bearer YOUR_API_KEY' \
  --header 'content-type: application/json' \
  --header 'X-API-Version: 2025-01-01.orion' \
  --data-raw '{
    "id": "onb-12345",
    "eval_id": "6dc8f39c-ecc3-4fe0-9283-fc8e5f99e816",
    "workflow": "consumer_onboarding",
    "data": {
      "individual": {
        "id": "9876543",
        "first_name": "John",
        "middle_name": "M",
        "last_name": "Doe",
        "national_id": "000-10-0007",
        "dob": "2002-07-28",
        "email": "[email protected]",
        "phone_number": "+447767198341",
        "docv": {
          "config": {
            "use_case_key": "customer_use_case_key",
            ...
          }
        },
        "address": {
          "line_1": "Address Line 1",
          "locality": "New York City",
          "major_admin_division": "NY",
          "country": "US",
          "postal_code": "12345"
        }
      }
    }
  }'
  1. When you receive the API response, collect the docvTransactionToken. This value is required to initialize the DocV Web SDK.
{
  "id": "Test-API-1",
  "workflow": "sc_onboarding",
  "workflow_id": "a8dff53b-74c1-411f-a43d-9597ae60e5ae",
  "workflow_version": "3.2.0",
  "eval_source": "API",
  "eval_id": "500c6b88-9f5c-4d62-9422-163a59a343fe",
  "eval_start_time": "2025-01-08T14:57:42.08985Z",
  "eval_end_time": "0001-01-01T00:00:00Z",
  "decision": "REVIEW",
  "decision_at": "2025-01-08T14:57:43.223321Z",
  "status": "ON_HOLD",
  "sub_status": "",
  "tags": null,
  "notes": "",
  "review_queues": [
    "Default Queue"
  ],
  "data_enrichments": [
    {
      "enrichment_name": "SocureDocRequest",
      "enrichment_endpoint": "https://service.socure.com/api/5.0/documents/request",
      "enrichment_provider": "SocureDocRequest",
      "status_code": 200,
      "request": {
        "city": "New York City",
        "country": "US",
        "dob": "2002-07-28",
        "firstName": "John",
        "mobileNumber": "+1234567891",
        "physicalAddress": "Address Line 1",
        "state": "NY",
        "surName": "Doe",
        "zip": "12345"
      },
      "response": {
        "data": {
          "docvTransactionToken": "70c6a4bc-f646-4c6a-94c1-9cd428e356ef",
          "eventId": "70c6a4bc-f646-4c6a-94c1-9cd428e356ef",
          "url": "https://verify.socure.com/#/dv/70c6a4bc-f646-4c6a-94c1-9cd428e356ef"
        },
        "referenceId": "aacdc975-0eb8-428d-9954-b42aab67f85f"
      },
      "is_source_cache": false,
      "total_attempts": 1
    }
  ],
  "eval_status": "evaluation_paused"
}

Step 2: Add the DocV Web SDK

To enable DocV SDK functionality, add the SDK script inside your <head> section:

<script src="https://websdk.socure.com/bundle.js"></script>

Add the handoff component

The handoff component is displayed on the webpage in a <div> element where the id="websdk" is provided.

<button onclick="start()">Start Verification</button>
<div id="websdk"></div>

When the consumer clicks Start Verification, the SDK launches inside the #websdk container. The following example displays the default screens for the handoff component:


Initialize and launch the SDK

To launch the SDK, configure the SocureDocVSDK.launch function in your front-end:

<html>
  <head>
    <script src="https://websdk.socure.com/bundle.js"></script>
  </head>
  <body>
    <button onclick="start()">Start Verification</button>
    <div id="websdk"></div>

    <script>
      var config = {
        onProgress: function (event) {
          /* Called during capture */
        },
        onSuccess: function (response) {
          /* Called on success */
        },
        onError: function (error) {
          /* Called on error */
        },
        qrCodeNeeded: true, // Show QR code option
        disableSmsInput: false, // Enable SMS input
        closeCaptureWindowOnComplete: true, // Auto-close tab after document upload confirmation
        autoOpenTabOnMobile: true, // Skip "Continue on New Tab" screen on mobile and launch Capture App in a new tab
      };
      function start() {
        SocureDocVSDK.launch(
          'SDKKey',
          'docvTransactionToken',
          '#websdk',
          config[optional]
        );
      }
    </script>
  </body>
</html>

SocureDocVSDK.launch function parameters

The following table lists the SocureDocVSDK.launch function parameters:

ParameterRequiredDescription
SDKKeyRequired

The unique SDK key obtained from RiskOS™ used to authenticate the SDK.

docvTransactionTokenRequired

The transaction token retrieved from the API response of the /api/evaluation endpoint. Required to initiate the document verification session.

websdkRequiredThe div element where the SDK should render the Web SDk handoff component.
configOptionalContains the callback methods for the progress, success, and error responses. See the section below for more information.

The config object and callback methods

You can pass a config object into the SocureDocVSDK.launch method to control behavior and handle events during the verification process.

var config = {
  onProgress: function(event) { ... },
  onSuccess: function(response) { ... },
  onError: function(error) { ... },
  qrCodeNeeded: true,
  disableSmsInput: false,
  closeCaptureWindowOnComplete: true,
  autoOpenTabOnMobile: true
};
📘

Note:

The callback functions are required. If you are not using them, the contents within the brackets may be left empty, but the functions themselves must still be defined.

The following table lists the arguments passed to the config object:

ParameterTypeRequiredDescription
onProgressFunctionRequiredCallback function triggered during the document capture process.
onSuccessFunctionRequiredCallback function executed when the document capture process completes successfully.
onErrorFunctionRequiredCallback function triggered when an error occurs during the document capture process.
qrCodeNeededBooleanOptionalDetermines whether a QR code is displayed on the handoff component. If true, the system generates a QR code.
disableSmsInputBooleanOptionalDisables the SMS entry option on the handoff component, showing only the QR code option. Setting this to true overrides qrCodeNeeded: false.
closeCaptureWindowOnCompleteBooleanOptionalAutomatically closes the Capture App browser tab 2 seconds after the consumer reaches the Confirmation screen at the end of the Capture App flow.Note: If a redirect.url is included in the redirect object of the Evaluation API call, or if a redirect URL is configured in the flow on the RiskOS™ Dashboard, the redirect will take precedence and this setting will be ignored.
autoOpenTabOnMobileBooleanOptionalAutomatically opens the Capture App in a new browser tab on mobile devices, bypassing the intermediate Continue on New Tab confirmation screen.

Handle the response

The SocureDocVSDK.launch() function returns a Promise that resolves with either a success or error result. This allows you to handle immediate initialization feedback on the client side. For example, if a transaction token is invalid or expired, you can request a new evaluation from your backend and retry launching the SDK.


Launch response handling

Success response:

{
  "result": "success"
}

Error response:

{
  "result": "error",
  "errorMessage": "<message>"
}

Possible error messages include:

CategoryError Message
Transaction ErrorsInvalid DocV Transaction Token (If loading transaction from Step Up fails)
Input ValidationPlease provide a valid public API key (If no key is provided)
You need to provide a W3C compatible selector to the init method. (If no selector is provided)
Invalid selector found (If selector is not found in the DOM)
Please provide a valid pollingInterval (If polling interval value is invalid)
SDK Load FailureFailed to load websdk (If WebSDK fails to load)

Reset the SDK

You can reset the DocV Web SDK by calling the SocureDocVSDK.reset() function in your front-end implementation.

This function will:

  • Clear the Web SDK cache.
  • Clean up stored data and API state.
  • On mobile browsers: if a captureAppWindow is active (opened by the Web SDK), it will automatically close the new tab window.

Example:

// Reset the Socure DocV SDK
SocureDocVSDK.reset();

Callbacks and webhooks

You can use either callbacks or webhooks to track the consumer's progress in the document capture and upload process, and receive error messages if the flow fails. For more information, see Predictive DocV Web SDK Callback Methods and Predictive DocV Webhook Events.


Step 3: Receive the verification results

After the consumer finishes the document capture and upload process with the Caprture App, RiskOS™ runs the evaluation process and returns the results in the evaluation_completed webhook event. The DocV verification results are included in the data_enrichments array within the payload.

Alternatively, you can fetch the RiskOS™ results by making a GET request to the <Anchor label="/api/evaluation" target="_blank" href="https://help.socure.com/riskos/update/reference/getevaluation">/api/evaluation</Anchor> endpoint.

{
  "data": {
    "decision": "REVIEW",
    "decision_at": "2025-04-08T18:27:31.924196163Z",
    "environment_name": "",
    "eval_at": "2025-04-08T18:27:31.924196043Z",
    "eval_id": "8770e076-f568-48a9-8201-dca13087e592",
    "eval_source": "API",
    "evaluation_status": "evaluation_completed",
    "id": "abc-test-123",
    "notes": "Test Notes",
    "reason_codes": ["test"],
    "review_queues": ["Default Queue"],
    "status": "OPEN",
    "sub_status": "Surveillance",
    "tags": ["test"],
    "data_enrichments": [
      {
        "third_party_name": "Socure Document Request",
        "third_party_endpoint": "https://service.socure.com/api/5.0/documents/request",
        "third_party_provider": "SocureDocRequest",
        "status_code": 200,
        "request": {
          "country": "US",
          "firstName": "John",
          "surName": "Smith"
        },
        "response": {
          "data": {
            "docvTransactionToken": "9979eda7-9694-476d-ab8b-e6bbc0153dc3",
            "eventId": "9979eda7-9694-476d-ab8b-e6bbc0153dc3",
            "url": "https://verify.socure.com/#/dv/9979eda7-9694-476d-ab8b-e6bbc0153dc3"
          },
          "referenceId": "b902702f-a07a-4180-acdd-20266f776ba3"
        },
        "is_source_cache": false,
        "total_attempts": 1
      },
      {
        "third_party_name": "Socure Predictive Document Verification Prod",
        "third_party_endpoint": "https://service.socure.com/api/3.0/EmailAuthScore",
        "third_party_provider": "Socure",
        "status_code": 200,
        "request": {
          "country": "US",
          "docvTransactionToken": "9979eda7-9694-476d-ab8b-e6bbc0153dc3",
          "firstName": "John",
          "modules": ["documentverification"],
          "parentTxnId": "e3c35948-5141-4e3d-836d-31ee7fcc8b8d",
          "surName": "Smith",
          "workflow": "api_consumer_onboarding"
        },
        "response": {
          "documentVerification": {
            "decision": {
              "name": "standard",
              "value": "accept"
            },
            "documentType": {
              "country": "USA",
              "state": "WA",
              "type": "Drivers License"
            },
            "reasonCodes": [
              "I834",
              "I845",
              "I831",
              "I820",
              "I836",
              "I838",
              "R823",
              "R822"
            ]
          },
          "referenceId": "06bf2f66-7d18-47c2-b12f-4be3a30e1d49"
        },
        "is_source_cache": false,
        "total_attempts": 1
      },
      {
        "third_party_name": "Socure Image Request Prod",
        "third_party_endpoint": "https://upload.socure.com/api/5.0/documents/{referenceId}",
        "third_party_provider": "SocureImageRequest",
        "status_code": 200,
        "request": {
          "referenceId": "06bf2f66-7d18-47c2-b12f-4be3a30e1d49"
        },
        "response": {
          "docId": "077bd0be-129e-4352-bb6b-cc07c9a86fdc"
        },
        "is_source_cache": false,
        "total_attempts": 1
      }
    ],
    "workflow": "api_consumer_onboarding",
    "workflow_id": "7ba6948f-502d-446e-a1e5-45d66cc50983",
    "workflow_version": "1.0.0"
  },
  "event_at": "2025-04-08T18:27:31.9244894Z",
  "event_id": "df9252b5-85c8-426e-9590-8f51b6e5b5c0",
  "event_type": "evaluation_completed"
}
